Product Description
Winding Solution for Riser-type Commutator Rotor
Wind Automation proivide customer with various winding solutions, for armature winding, for coil winding, for stator winding, for needle winding, for hairpin winding.
(1)Specification
| Wire range | 0.2~1.2mm |
| Armature OD | 20~90mm |
| Stack height | 10~130mm |
| Commutator OD | 8~60mm |
| Movement | Jog/auto |
| Slot No. | Odd/Even |
| Turn No. | 0~9999 |
| Flyer speed | 0~2000rpm |
| Power supply | AC 220V 50/60HZ |
| Air source | 5~7kg/cm3 |
| Power | 3.5KW |
| Weight | 830KG |
| Dimension | 1530x1280x1650mm |
(2)Feature
For riser type commutator
With medium and big wire diameter
Manual loading and unloading
Can work as a stand-alone machine or integrated into a production line
All winding parameter programmed on touch screen
This machine is suitable for slotted type armature with riser type commutator.
(4)Machine Operation
1)Put the armature on the tooling
2)Then press the start button.
3)Machine will wind the armature automatically
4)Unload wound armature
